This document specifies minimum requirements for the materials, design, construction, type testing and routine manufacturing inspections of composite gas cylinders and tubes for compressed hydrogen.
NOTE 1 - Unless specified in the text, for the purposes of this document, the word "cylinder" includes tubes.
This document applies to:
- fully wrapped composite cylinders (Type 3 and Type 4);
- hoop wrapped cylinders (Type 2);
with carbon fibres, intended to be permanently mounted in a frame (e.g. bundle or trailer) with a test pressure of not less than 300 bar, with:
- non-metallic liners (Type 4) or seamless metallic liners (for Type 2 and Type 3);
- a maximum water capacity of 3 000 l;
- a maximum working pressure of 1 000 bar;
- the product of working pressure times water capacity (p x V) not exceeding 1 000 000 bar.l.
NOTE 2 - A glass fibre protective layer is sometimes applied to the external surface of the cylinder.
Označení | ČSN EN 17339 (078553) |
---|---|
Katalogové číslo | 521108 |
Cena | 550 Kč550 |
Datum schválení | 1. 5. 2025 |
Datum účinnosti | 1. 6. 2025 |
Jazyk | angličtina (obsahuje pouze anglický originál) |
Počet stran | 52 stran formátu A4 |
EAN kód | 8596135211081 |
Tato norma nahradila | ČSN EN 17339 (078553) z prosince 2020 |
Dostupnost | skladem (tisk na počkání) |
