ČSN EN 16605 (310580)

Kosmos - Časovač přijímacího zařízení Galileo - Funkční a výkonnostní požadavky a související zkoušky

ČSN EN 16605 Kosmos - Časovač přijímacího zařízení Galileo - Funkční a výkonnostní požadavky a související zkoušky
titulní stránka
(kliknutím zvětšíte)
Objednat
Cena: 945 Kč
včetně 0 % DPH
ks
skladem
tisk na počkání

Anotace obsahu normy

This document specifies the functional and performance requirements and associated tests for Galileo timing receivers. The approach for this document is that of a performance based, meaning that no specific algorithm implementation is required. Instead, performance requirements are specified together with a corresponding test suite for verification.
This document is applicable to the Galileo chipset. This document does not apply to other sensors and/or additional processing that a higher synchronization Unit can implement on top of the Galileo chipset.
This document is applicable to the following aspects related to Galileo timing receivers:
- GNSS constellations and frequencies processed: Galileo Dual-Frequency. Other modes are optional, as explained below;
- time scales, including Galileo System Time and Coordinated Universal Time;
- Services Levels, this document covers the 2 levels of Service for GST and for UTC to be provided by Galileo Time Service in the first place. The document also anticipates a third Service Level to be provided in the future, for which an update of the document will be needed;
- user dynamics: fixed users, defined as static users with precise knowledge of the antenna position, is the baseline mode;
- processing of Timing Service Message disseminated by the Galileo System;
- local timing integrity barriers: As a minimum, Time Receiver Autonomous Integrity Monitoring processing (T-RAIM);
- robustness to interferences;
- Galileo Open Service Navigation Message Authentication processing;
- robustness to multipath.
This document does not apply to the processing of GPS constellation but this does not preclude Manufacturers to implement GPS processing within the Galileo timing receivers, even if not addressed in this document. The use of other GNSS constellations is not forbidden by this document but the requirements and tests are defined considering Galileo-only, including those related to the integrity of the timing solution.
This document does not apply to single-frequency modes. This does not preclude manufacturers to implement single-frequency modes within the Galileo timing receivers, even if not addressed in this document, as a back-up of the nominal Dual-Frequency mode, and reversion mechanisms. It is important to remark that the integrity of the timing solution is only specified for Galileo Dual-Frequency mode.
The Galileo timing receivers is only applicable to users operating in static conditions. This document does not apply to moving users.
On top of the functional requirements, performance requirements are specified in this document in terms of different key performance indicators such as:
- accuracy, availability and integrity requirements;
- local barriers, T-RAIM performances.
This document also provides the verification matrix and specifies the test suite to verify the most fundamental requirements of the Galileo timing receivers.
Finally, this document specifies a subclause dedicated to guidelines for the installation and maintenance of the Galileo timing receivers. This is a comprehensive subclause, including provisions for the antenna, cabling and receiver installation, as well as the calibration of time delays.

Označení ČSN EN 16605 (310580)
Katalogové číslo 521078
Cena 945 Kč945
Datum schválení 1. 5. 2025
Datum účinnosti 1. 6. 2025
Jazyk angličtina (obsahuje pouze anglický originál)
Počet stran 116 stran formátu A4
EAN kód 8596135210787
Dostupnost skladem (tisk na počkání)
